Product Introduction:
Oil immersed non partial discharge test transformer refers to a test transformer with no or very small partial discharge capacity, suitable for conducting partial discharge tests and power frequency withstand voltage tests on various electrical equipment, electrical components, and insulation materials.
Technical parameters:
پارامتر | قیمت |
ظرفیت رتبه بندی شده | 50-1200kVA |
Input voltage | 380 ولت |
ولتاژ خروجی | 50-1200kV |
Run time | ≤ 5 minutes |
دقت اندازه گیری | ≤1.5% |
Partial discharge capacity | ≤5Pc |
Protection function | Overcurrent and voltage protection alarm automatically return to zero |
Product Features:
1. Adopting an oil type epoxy cylinder structure, it has small partial discharge, low loss, light weight, and low waveform distortion.
2. Low impedance voltage, superior to national standards.
3. Multi layer shielding, strong anti-interference ability.
4. High insulation level, local discharge capacity ≤ 5pc.
5. Equipped with automatic protection device, over-current and over-voltage protection, and high reliability performance.
